High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox

1
MOQ
$5500~8000
Price
High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox
Features Gallery Product Description Request A Quote
Features
Specifications
Computerized: Yes
Guarantee Time: 1 Year
Production Capacity: 0 - 10 M/min
Cutting Edge Height: ≤ 300 Mm
Highlight:

computerized dual filter gluing system

,

fast curing gluing system for bearings

,

high-precision gearbox filter production line
Basic Infomation
Place of Origin: Anhui,China
Brand Name: TONGCHEN
Certification: ISO
Model Number: TC-5569
Payment & Shipping Terms
Packaging Details: Wooden Box
Delivery Time: 30
Payment Terms: T/T
Supply Ability: 15
Product Description
High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox
Fast and reliable high-output production AB Two Component Filter Gluing Machine designed for industrial settings. Built with durable carbon-steel structure and equipped with Mitsubishi PLC and Weintek touchscreen controls, this machine delivers advanced real-time mixing, intelligent monitoring, and automated cleaning capabilities.
Technical Specifications
Structure Carbon steel painted structure
Control System Self-R&D program; Mitsubishi PLC + Weintek touchscreen
Stock Buckets A: 30L carbon steel with heating; B: 30L carbon steel with heating; both with heating function, feeding funnel, inspection glass, full/empty alarms
Mixing Scale Main scale 2:1 (adjustable); overall 10:1-10:10 adjustable; digital input
Measuring Pump A pump: 6CC gear pump; B pump: 3CC gear pump
Glue Supply System Leisa stepper motor/driver + gear pump
Discharging Method Static mixing valve discharge
Air Pressure Requirement 0.5-0.7 MPa
Power Supply 220V / 50Hz
Discharge Speed 1-25 g/s
Discharge Accuracy ±2%
Programs & Functions One-touch cleaning; timed/metered dispensing; anti-solidifying; low-pressure alarm; abnormal fault alarm
Monitoring Features Output counting; timing; operational supervision alarms
High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox 0
Key Features
  • Precise Adjustable Dispensing: Glue output size, dispensing time, and ratio can be adjusted via digital parameters, ensuring accurate dispensing without dripping or leakage.
  • On-Demand Mixing & Maximum Glue Savings: Real-time ratio adjustment enables simultaneous mixing and dispensing, minimizing adhesive waste and improving cost efficiency.
  • Dual-Bucket Storage System: Separate 30L heated A/B buckets prevent premature curing and ensure stable adhesive properties during long-term storage.
  • Wide Ratio Range with Static Mixing: Adjustable mixing ratio from 10:1 to 10:10 with static mixing valves ensures uniform and thorough blending.
  • Comprehensive Alarm System: Includes low air-pressure alarm, material shortage/full alarm, contamination alarm, and abnormal fault warnings.
  • Automatic Liquid Level Detection: Buckets equipped with level switches provide automatic shortage/full alarms and machine auto-stop protection.
  • Smart Monitoring & Productivity Tracking: Features yield counting, individual piece timing, and operational monitoring with alarm alerts.
  • Advanced Auto-clean Functions: Multiple cleaning modes for different adhesive types, plus one-touch auto-cleaning of mixing tubes and valves.
  • Anti-solidifying Program: Prevents adhesive curing inside pipes and valves during temporary stops.
  • Built-in Weighing System: Unique weighing function simplifies ratio adjustments and enhances precision.
  • Digital Speed Control: Electronic dispensing-speed control allows easy fine-tuning of adhesive output volume.
Packaging & Delivery
Selling Units: Single item
High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox 1
Manufacturer Profile
Bengbu Tongchen Automation Technology Equipment Co., Ltd. is located in Bengbu, China—an important transportation hub and industrial base. Our company specializes in the development, design, and production of filter manufacturing equipment, providing advanced, practical, and efficient solutions that meet both domestic trends and international standards.
Product Range
  • Paper folding equipment and rotating machines
  • Diesel engines and large air filter production equipment
  • Partitionless and partitioned filter production equipment
  • Pleating machines and glass fiber strip production lines
High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox 2 High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox 3 High-Precision Computerized Dual Filter Gluing System Fast Curing Technology for Bearing Gear Motor Engine Gearbox 4
