Stable Automotive Filter Manufacturing Machines Long Side Filter Strainer Welt Equipment

1
MOQ
30000-40000
Price
Stable Automotive Filter Manufacturing Machines Long Side Filter Strainer Welt Equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Power Source: Electric
Machinery Test Report: Provided
Guarantee Time: 1 Year
Dimension: 3800*950*1395 Mm (L*W*H)
Computerized: Yes
Product Origin: Bengbu Anhui China
Highlight:

automotive filter manufacturing machines

,

long side filter strainer equipment

,

air filter production line equipment
Basic Infomation
Place of Origin: Anhui Bengbu
Brand Name: Bengbu Tongchen
Certification: CE/ISO
Model Number: TCFH-700
Payment & Shipping Terms
Packaging Details: Wooden Box
Delivery Time: 15-45 Days
Payment Terms: T/T
Supply Ability: Unlimited Supply
Product Description
Stable Automotive Filter Manufacturing Machines
Our production line specializes in manufacturing high-temperature resistant glass fiber folded filter paper, designed for demanding industrial applications. The equipment integrates cutting-edge automation technology to ensure precision folding, uniform adhesive application, and high-speed production of filter cores used in HEPA/ULPA filters, automotive filtration, and thermal insulation systems.
Product Specifications
Pre-cutting Paper Conveying Machine
Parameter Specification
Paper feeding speed 0.5m/min - 10m/min adjustable
Adjustable width 25 - 350mm
Filter paper thickness 1.5mm
Power supply voltage 380V/50Hz
Motor power 0.55kw
Working air pressure 0.6Mpa
Machine weight 250kg
Dimensions 1280×1100×1200mm (L×W×H)
Folding Machine
Parameter Specification
Maximum product width 1000mm
Adjustable folding height 25 - 120mm
Folding speed 0 - 60 folds/minute (adjustable)
Glass fiber line distance 32mm
Power supply voltage 380V - 50Hz
Main motor power 4×0.75kw
Ascending motor power 0.4KW
Working air pressure 0.6Mpa
Machine weight 450kg
Dimensions 1800×1500×2250mm (L×W×H)
Main Features
  • Feeding function
  • Powder brake, air expansion shaft, tension regulator, tension can be freely adjusted
  • Feeding roller, conveying roller, both ends of the conveying roller have an adjustable cylinder
  • Customized cutting knife
  • Line cutting is customized according to the line width, automatic cutting of the upper and lower layers through special processing materials to control the stability of the lines
  • Pre-cutting paper feeding machine is the latest improved cutting machine, the cutting lines adopt servo control system for synchronous movement with the folding machine
  • Upper and lower lines and filter paper are automatically synchronous with folding
Stable Automotive Filter Manufacturing Machines Long Side Filter Strainer Welt Equipment 0
Product Advantages
Precision & Flexibility
Multi-Layer Compatibility: Handles up to 7 layers of materials (glass fiber, PP, metal, etc.) with automatic height adjustment. Dual-Side Processing: Simultaneous cutting and folding reduce production time by 30% compared to traditional methods.
Durability & Efficiency
High-Temperature Resistance: Processes glass fiber paper stable up to 500°C, ideal for industrial kilns and automotive exhaust systems. Energy-Saving Design: Servo motors and PLC reduce power consumption by 15% (total power: 16kW).
Smart Automation
Touchscreen Control: Real-time parameter adjustment (speed, fold height, tension) via HMI interface. Quick Changeover: Modular rollers and pre-set recipes minimize downtime for multi-product batches.
Applications
  • Automotive Air Filters
  • Cabin Filters
  • Industrial Dust Filters
  • Air Purification Filters
  • HEPA Filter Production Lines
Company Profile
Stable Automotive Filter Manufacturing Machines Long Side Filter Strainer Welt Equipment 1
Established in 2011, Bengbu Tongchen Automation Technology Equipment CO.,LTD is a specialized firm that integrates research, development, manufacturing, marketing and after-sales service for filtration equipment manufacturing equipment. Our primary product offerings encompass a range of advanced machinery, including fully automated reciprocating paper folding production lines, fully automated PP intermittent glue injection and wave reception production lines, and fully automated paper frame gluing production lines. For more information or to schedule a demonstration, please contact us. We are committed to providing tailored solutions that meet the unique needs of our clients.
Production Packaging
Stable Automotive Filter Manufacturing Machines Long Side Filter Strainer Welt Equipment 2 Stable Automotive Filter Manufacturing Machines Long Side Filter Strainer Welt Equipment 3
Frequently Asked Questions
Can you give me a discount price?
Discounts depend on order volume. Larger quantities qualify for greater discounts.
How do you guarantee your quality?
Our experienced workers and technical staff ensure product quality. All products undergo thorough inspection by quality control personnel before shipment.
How about your after-sales service?
We provide professional technical support through our dedicated service team, available for online guidance and troubleshooting.
