Name: Full-auto Rotary HDAF Paper Pleating Producing Line
Brand: Bengbu Tongchen Automation Technology Co., ltd
SKU: TCZZJ
Price: 22,000.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Name: Paper Production Line

Construction: Hepa Filter

Material: Paper

Type: Filter Pleating Machine

Welder: Spot Welding

Weight: 450kg

Control System: PLC

Folding Type: Z-Fold

Touchscreen Configuration: 10-inch Touch Screen(brand:INOVANCE)

Basic Infomation

Place of Origin: Bengbu, China

Brand Name: TONGCHEN

Model Number: TCZZJ

Payment & Shipping Terms

Packaging Details: wooden box

Delivery Time: 15~45 work days

Payment Terms: T/T

Supply Ability: 30 sets per day

Gallery

Full-auto Rotary HDAF Paper Pleating Producing Line

Product Description

Full-auto Rotary HDAF Paper Pleating Producing Line

Customized products are available in various types.

Each product has its own price.

For detailed product information and to inquire about the price, please contact the customer service.

The more quantity, the better price.

Products Description

This machine incorporates multiple advanced functionalities for efficient filter paper processing:

Pneumatic Cutting System: Equipped with a pneumatic cutting knife for easy adjustment, convenient operation, and uniform pressure during pre-slitting.
Pre-Heating & Steam Device: Features pre-heating and steam mechanisms to prevent filter paper from tearing or damage during crease folding.
Gear Claw Wave-Collecting Mechanism: Includes a gear claw system to accelerate pleating speed while ensuring the folded paper remains flat and straight.
Crease Roll Flexibility: Utilizes crease rolls to form "S"-shaped or diamond-shaped pockets on the paper surface, maintaining uniform and consistent spacing between pleats.
High Automation: Automatically completes processes such as dot marking, counting, pleating, pre-heating, and shaping on the production line, demonstrating a high degree of automation.
Computerized Control: Operates via computer control, offering user-friendly and intuitive operation.

Full-auto Rotary HDAF Paper Pleating Producing Line 0

Product Parameters

Product parameters for reference only, details consult customer service.

Machine Name	Full-auto Rotary HDAF Paper Pleating Producing Line
Temperature Control	0-300degrees
Slitting width range	50-850mm (Minimum slitting width 50mm, customizable widening up to 850mm is supported)
Slitting accuracy	±0.15mm (static) /±0.3mm (dynamic, during high-speed operation)
Maximum load capacity of the discharge rack	500kg (standard single station) /1000kg (optional double station with automatic switching)
Slitting speed	0-180m/min (adjustable, depending on the material thickness. When the glass fiber is 0.5mm, it is recommended to be ≤150m/min)
