Premium G4 Air Filter Production Line | 95% Efficiency for 5μm Particles | Automated Manufacturing for Industrial HVAC Systems

• - Drive and Positioning: It adopts a full servo motor drive system, combined with visual inspection and laser positioning modules. The folding error of the pleated paper is ≤±0.1mm, and the positioning accuracy of the glue line reaches ±0.2mm, ensuring the precise position of folding and gluing.
• - Process compatibility: Supports filter paper specifications with pleat distances ranging from 5 to 30mm and pleat heights from 10 to 80mm. It is suitable for filter papers made of various materials such as chemical fibers, wood pulp, and glass fibers. It is also compatible with various types of adhesives including hot melt adhesives, water-based adhesives, and UV adhesives. The glue volume can be adjusted within the range of 0.1 to 5g/m², and it can automatically match material and process requirements.
• - Production efficiency: The maximum operating speed reaches 15 meters per minute, supports multi-specification program storage (≥50 groups), and it only takes 30 minutes to change product models. The annual production capacity can reach 5 to 10 million pieces.
• - Intelligent control: Equipped with a 10.1-inch touch screen, it integrates real-time monitoring of glue quantity, self-diagnosis of faults, and production capacity statistics functions. It supports remote Internet of Things monitoring, with energy consumption ≤20kW/h, saving 25% energy compared to traditional equipment.

This equipment, with its high parameter compatibility and intelligent regulation capabilities, meets the high-precision production demands of filter pleated paper in the automotive, industrial, medical and other fields, significantly enhancing the sealing performance of filter elements and production efficiency.

Customized products are available in various types. Each product has its own price. For detailed product information and to inquire about the price, please contact the customer service. The more quantity, the better price.Contact me as soon as possible.
