Intelligent operation and management:

-15-inch touch interface: Equipped with a user-friendly operating system, it supports functions such as pre-storage of production parameters (capable of storing)

 ≥50 sets of process formulas), real-time production capacity statistics, and self-diagnosis of equipment faults, lowering the operation threshold and enhancing production management efficiency.
- Data-driven production traceability: Integrating production data recording and export functions, it can trace the process parameters and quality data of each batch of products, helping enterprises achieve standardized management and quality control upgrades.

Application scenarios:

- Filtration field: High-efficiency/ultra-high-efficiency air filter elements, liquid filtration materials, etc.
- Insulation field: Base materials for electrical insulation boards, heat insulation materials for electronic devices;
- Composite materials: Automotive lightweight reinforcing materials, composite plates for aerospace.

Technical parameters:

Project indicators
The fiber diameter ranges from 5 to 25μm
Applicable raw materials: E glass, C glass and special glass fibers
The width range of the filter material is 300-1200mm
The pleat height ranges from 40 to 75mm
The drive mode is fully servo motor drive
The control accuracy is ±0.1mm for laser positioning and ±1℃ for temperature control
Production capacity efficiency Continuous production speed: 5-15m/min (adjustable)
