Full-Automatic Servo Paper Folding Production Line (5th Generation)

1. All-Servo Drive Technology
   • Eliminates traditional gears and timing belts, adopting INOVANCE full-digital servo motors (5 sets) and electronic cam control for ±0.1mm positioning accuracy.
   • Enables dynamic adjustment of folding angles (upper/lower blade opening/closing) for complex patterns (W-type, M-type, multi-layer folds).
2. Intelligent Production Management
   • Recipe function stores 50+ folding programs for quick model switching, reducing setup time by 60%.
   • Three-color alarm system (green/amber/red) for real-time fault diagnosis, minimizing downtime.
3. Medical-Grade Safety & Quality
   • Electroplated hard chrome shafts and powder-coated steel frame ensure corrosion resistance and 100,000+ hours of service life.
   • Five pneumatic pressure plates with tension control guarantee stable material output, critical for multi-layer medical fabrics.
4. Energy-Efficient Heating
   • Dual heating plates (3 zones each) with PID temperature control (±2°C accuracy) enable rapid bonding of melt-blown fabrics, reducing energy consumption by 15% compared to older models.

Project Outcome

• Efficiency: Increased production capacity from 150 to 280 folds/min, meeting the client’s demand for 500,000 masks/day.
• Compliance: Successfully passed EU MDR audit with CE-certified safety features (e.g., emergency stop via safety grating).
• Flexibility: Adapted to produce N95, FFP2, and custom medical filters, supporting the client’s expansion into aerospace and industrial filtration markets.
